- SHOTPlus™ Variant:
- Surface
- Version:
- 6.0.0 and above
- KBA Summary:
- This Knowledge Base Article detail how to use the Hole Profile Logging tool in SHOTPlus™.
Summary
The tutorial video below explains how to use the Hole Profile Logging tool and the rule application to identify strata intercepts within a profile trace in SHOTPlus™. The Hole Profile Logging tool supports multiple hole profile tracers imported in a hole.
In the example, holes already have profile tracers associated and can be identified with a symbol marked as (y) next hole id.
